Crydom has combined solid state and mechanical switching technologies to create a contactor with longer operational life than standard EMR’s in an industry standard package!

Crydom, an operation of Custom Sensors

and Technologies (CST) and global expert in solid state relay technology, introduces a new line of high power Hybrid Solid State Contactors for use in Heating and Lighting applications where Mercury Displacement Relays have previously been applied, and where life cycle constraints limit the use of Definite Purpose Contactors.

Mounting identically to a standard 3 phase DP (Definite Purpose) contactor, and featuring full load life cycle ratings of greater than 2 million operations, the new RHP line includes 3 phase contactor configurations rated at 120, 240, 280 or 600 VAC at 40 or 50 amp load ratings per phase at 65 degrees C ambient temperature. Control voltages of 24, 120 or 220 VAC, and unique logic compatible 5, 12 or 24 VDC input control options are offered. The RHP line is UL and cUL approved and CE certified...

Minneapolis, Minnesota – The RoHS, UL / CUL recognized RA Series rocker offered by CIT Relay & Switch has eight switch function choices including an LED option with On-Off function. The RA series offers housing color choices of black, white and grey with six actuator color choices making this extremely versatile rocker switch a go-to for electrical

designers. Teamed with thirteen actuator marking choices and three LED colors, and terminals options including quick connect, solder lug, PC pins, right angle PC pins and left angle PC pins, the RA Series rocker fits a wide variety of applications.

Specifications: Switch function is single pole single throw or single pole double throw. Electrical ratings are 15A at 125VAC or 8A at 250VAC. Electrical life is 10k cycles with contact resistance of less than 50m. Dielectric strength is 1500Vrms and insulation resistance is greater than 100M. Operating temperature and storage temperature are -40°C to 85°C...

Octal sockets offer a one-stop solution for your relay system. Features Include:

• Flip-up I.D. tag/Write-on plastic label - Allows for identification of circuits in multi-circuit applications.
• Ink marked terminals - Simplifies identification.

• Ink marked terminals - Simplifies identification.
• Mating hold-down clips - Secures relay to socket.
• Din rail and end clip - Enables quick installation of sockets, holds them firmly in place and allows for easy removal.
• Flexible mounting - Mounts to panel or fit to 35 mm din rail.
• Internal coil bus jumper - Allows connection to adjacent sockets without additional wiring.
• Finger-safe terminals - Protects operator from live circuits.
• Module compatible - Allows for use of optional protection and led modules.
