Panel Space-Savers - 17.5mm modular products
MULTI-FUNCTION TIME DELAY RELAYS - TE-881 Series
The TE-881 Series time delay relays offer 10 timing functions and a universal voltage input (12-240VAC/DC) with a programmable time range from 0.1 second - 10 days all in one compact unit. Choose between versions with 15A SPDT or DPDT output contacts. A green LED indicates input voltage applied; a red LED blinks during timing & is steady when the output relay is energized. These products have a compact 17.5mm enclosure which snaps on to 35mm DIN track. This conserves space & reduces installation time, which saves money. With all this flexibility, the TE-881 Series replaces hundreds of separate time delay relays.
Features
VOLTAGE SENSING RELAYS - VWKE Series
Provides protection to equipment that is required to operate within an upper & lower AC single phase or DC voltage limit. As long as the monitored voltage (Un) remains between the OVER (Umax) & UNDER (Umin) voltage settings, the internal relay stays energized. If the monitored voltage falls outside this range, the relay will drop-out. The Umax dial sets the upper trip setting per the Overvoltage range of the product. The Umin dial sets the lower trip setting at 30-95% of the upper setting. These products have an adjustable time delay on drop-out of 0.1-10 seconds (t) to prevent nuisance tripping. They have a compact 17.5mm enclosure which snaps on to 35mm DIN track. This conserves space & reduces installation time, which saves money.
