Image Series Type Contact Arrangement Contact Rating Coil Voltage Mounting Methods
CIT Relay and Switch J097 Series UL Approved Relay
 J097 Series UL Approved 1C 10A @ 120VAC/277VAC, 5A @240VAC, 3A@30VDC, TV-5@120VAC, 1/4hp @ 120/240/277VAC 3VDC, 5VDC, 6VDC, 9VDC, 12VDC, 18VDC, 24VDC, 48VDC PC Pin
CIT Relay and Switch J099 Series UL Approved Relay
 J099 Series UL Approved 1A 10A@277VAC General Purpose 100K cycles, 10A@30VDC General Purpose 100K cycles, 12A@125VAC Resistive 100K cycles 12VDC, 24VDC PC Pin
CIT Relay and Switch J100 Series UL Approved Relay
 J100 Series UL Approved 1A 10A@120VAC Resistive, 10A@277VAC Resistive, 5A@240VAC Resistive, 3A@30VDC Resistive, TV-5@120VAC, 1/4hp@120/240/277VAC 3VDC, 5VDC, 6VDC, 9VDC, 12VDC, 18VDC, 24VDC, 48VDC PC Pin
CIT Relay and Switch J102 Series UL Approved Relay
 J102 Series UL Approved 1A, 1B, 1C AgNi: 3A & 5A@125VAC General Purpose, 3A & 5A@30VDC Resistive; Ag: 1A & 3A@120VAC General Purpose, 1A & 3A@30VDC Resistive, Pilot Duty 270VA 120VAC 3VDC, 5VDC, 6VDC, 9VDC, 12VDC, 24VDC PC Pin
CIT Relay and Switch J103 Series UL Approved Relay
 J103 Series UL Approved 1C 2A@120VAC Resistive, 2A@24VDC Resistive 3VDC, 5VDC, 9VDC, 12VDC, 24VDC PC Pin
CIT Relay and Switch J104A Series UL Approved Relay
 J104A Series UL Approved 2C 2A@30VDC Resistive, 3A@30VDC N.O. Resistive, .6A@125VAC Resistive 3VDC, 5VDC, 9VDC, 12VDC, 24VDC, 48VDC PC Pin
CIT Relay and Switch J104B Series UL Approved Relay
 J104B Series UL Approved 2C 2A@30VDC Resistive, 3A@30VDC N.O. Resistive, .6A@125VAC Resistive 3VDC, 5VDC, 9VDC, 12VDC, 24VDC, 48VDC PC Pin
CIT Relay and Switch J104C Series UL Approved Relay
 J104C Series UL Approved 2C 1A@24VDC Resistive, 1A@125VAC Resistive 5VDC, 9VDC, 12VDC, 24VDC PC Pin
CIT Relay and Switch J104D Series UL Approved Relay
 J104D Series UL Approved 2C 2A@24VDC Resistive, 1A@120VAC Resistive 3VDC, 5VDC, 6VDC, 9VDC, 12VDC, 24VDC, 48VDC PC Pin
CIT Relay and Switch J105D Series UL Approved Relay
 J105D Series UL Approved 1A, 1C NO: 10A@120VAC Resistive, 10A@277VAC Resistive, 5A@240VAC Resistive, 3A@30VDC Resistive, TV-5@120VAC, 1/4hp@120/240/277VAC; NC: 10A@120VAC Resistive, 5A@240VAC Resistive, 3A@30VDC Resistive, 1/4hp@120/240/277VAC 3VDC, 5VDC, 6VDC, 9VDC, 12VDC, 18VDC, 24VDC, 48VDC PC Pin
CIT Relay and Switch J107E3 Series UL Approved Relay
 J107E3 Series UL Approved 1A, 1B, 1C 10A@250VAC, 10A@30VDC 3VDC, 5VDC, 9VDC, 12VDC, 24VDC, 48VDC PC Pin
CIT Relay and Switch J107F Series UL Approved Relay
 J107F Series UL Approved 1A, 1B, 1C 20A Contact: 20A@16VDC & 125VAC General Purpose, 10A@250VAC General Purpose, 1/3hp@125VAC & 277VAC, Normally Open 10A @ 250VAC; 15A Contact: 15A@125VAC General Purpose, 6A@277VAC General Purpose, Normally Open 15A @ 125VAC, 4FLA, 40 LRA @24VDC DC Motor; 12 3VDC, 5VDC, 9VDC, 12VDC, 24VDC, 48VDC PC Pin
CIT Relay and Switch J109F Series UL Approved Relay
 J109F Series UL Approved 1A, 1B, 1C 10A Contact: 6A@28VDC & 300VAC Resistive, 10A@28VDC & 125VAC General Purpose; 12A Contact: 12A@28VDC & 125VAC General Purpose, 1/3hp@120VAC & 240VAC 5VDC, 9VDC, 12VDC, 24VDC, 48VDC PC Pin
CIT Relay and Switch J113 Series UL Approved Relay
 J111 Series UL Approved 1A, 1C 16A@250VAC Resistive, 10A@250VAC Resistive 5VDC, 12VDC, 24VDC PC Pin
CIT Relay and Switch J113 Series UL Approved Relay
 J113 Series UL Approved 1A 5A@277VAC Resistive, 5A@30VDC Resistive 5VDC, 12VDC, 18VDC, 24VDC PC Pin
CIT Relay and Switch J114AF Series UL Approved Relay
 J114AF Series UL Approved 1A, 1C, 2A, 2C 1A & 1C: 16A@250VAC & 30VDC Resistive 70C; 1AH & 1CH: 16A@240VAC & 30VDC Resistive; 2A & 2C: 8A@250VAC Resistsive 70C, 5A@30VDC Resistive 70C 3VDC, 5VDC, 6VDC, 9VDC, 12VDC, 15VDC, 24VDC, 48VDC PC Pin
CIT Relay and Switch J114FL Series UL Approved Relay
 J114FL Series UL Approved 1A, 1C, 2A, 2C 12A@250VAC & 30VDC General Purpose 85C, 16A@250VAC & 30VDC General Purpose 85C, 8A@250VAC & 30VDC General Purpose 85C 5VDC, 6VDC, 9VDC, 12VDC, 24VDC, 48VDC PC Pin
CIT Relay and Switch J115f1 Series UL Approved Relay
 J115F1 Series UL Approved 1A, 1B, 1C NO: 40A@240VAC Resistive, 20A@240VAC Resistive 250K cycles, 30A@277VAC General Purpose, 25A@277VAC Resistive 100K cycles, 5A@280VAC Ballast, 2hp@250VAC; 1hp@125VAC 50K cycles 40C; NC: 30A@240VAC Resistive, 20A@240VAC General Purpose, 20A@277VAC General Pur 5VDC, 9VDC, 12VDC, 24VDC, 48VDC, 110VDC, 12VAC, 24VAC, 110VAC, 120VAC, 220VAC, 240VAC, 277VAC PC Pin
CIT Relay and Switch J115F2 Series UL Approved Relay
 J115F2 Series UL Approved 1A, 1B, 1C NO: 40A@240VAC Resistive, 20A@240VAC Resistive 250K cycles, 30A@277VAC General Purpose, 25A@277VAC Resistive 100K cycles, 5A@280VAC Ballast, 2hp@250VAC, 1hp@125VAC 50K cycles 40C; NC: 30A@240VAC Resistive, 20A@240VAC General Purpose, 20A@277VAC General Pur 5VDC, 9VDC, 12VDC, 24VDC, 48VDC, 110VDC, 12VAC, 24VAC, 110VAC, 120VAC, 220VAC, 240VAC, 277VAC PC Pin
CIT Relay and Switch J115F3 Series UL Approved Relay
 J115F3 Series UL Approved 1A, 1B, 1C NO: 40A@240VAC Resistive, 20A@240VAC Resistive 250K cycles, 30A@277VAC General Purpose, 25A@277VAC Resistive 100K cycles, 5A@280VAC Ballast, 2hp@250VAC, 1hp@125VAC 50K cycles 40C; NC: 30A@240VAC Resistive, 20A@240VAC General Purpose, 20A@277VAC General Pur 5VDC, 9VDC, 12VDC, 24VDC, 48VDC, 110VDC, 12VAC, 24VAC, 110VAC, 120VAC, 220VAC, 240VAC, 277VAC Panel Mount
CIT Relay and Switch J115F 50 AMP Series UL Approved Relay
 J115F 50Amp Series UL Approved 1A, 1B, 1C NO: 50A@240VAC; NC: 35A@240VAC 5VDC, 9VDC, 12VDC, 24VDC, 48VDC, 110VDC PC Pin, Panel Mount
CIT Relay and Switch J115F E Series UL Approved Relay
 J115F E Series UL Approved 1A, 1B, 1C UL Spec: NO 30A@240VAC & 14VDC, NC 20A@240VAC & 14VDC; TUV Spec: NO 30A@240VAC Resistive, NC 20A@240VAC Resistive 5VDC, 9VDC, 12VDC, 24VDC, 48VDC, 110VDC PC Pin, Panel Mount
CIT Relay and Switch J117F Series UL Approved Relay
 J117F Series UL Approved 1A, 1C 8A@250VAC, 8A@30VDC 100K cyces 70C 5VDC, 12VDC, 24VDC PC Pin
CIT Relay and Switch J118 Series UL Approved Relay
 J118 Series UL Approved 1A, 1B, 1C NO: 10A@120VAC Resistive, 20A@14VDC Resistive; NO: 10A@14VDC Resistive, 1/2hp@125VAC, TV-5@120VAC 9VDC, 12VDC, 24VDC PC Pin
CIT Relay and Switch J120D Series UL Approved Relay
 J120D Series UL Approved 1A 20A@125VAC, 16A@277VAC, 10A@250VAC General Purpose 20K 85C, 1hp@125/250 NO, 1/2hp@125/250 NC, TV-8@120VAC 5VDC, 6VDC, 9VDC, 12VDC, 24VDC, 48VDC PC Pin
CIT Relay and Switch J123F Series UL Approved Relay
 J123F Series UL Approved 1A, 1C 20A@125VAC, 16A@277VAC, 10A@250VAC General Purpose 20K 85C, 1hp@125/250 NO, 1/2hp@125/250 NC, TV-8@120VAC 5VDC, 6VDC, 9VDC, 12VDC, 24VDC, 48VDC PC Pin
CIT Relay and Switch J151 Series UL Approved Relay
 J151 Series UL Approved 1A, 2A, 3A, 4A, 1B, 2B, 3B, 4B, 1C, 2C, 3C, 4C 1 Pole: 20A@277VAC & 28VDC General Purpose; 2~4 Pole: 12A@250VAC & 28VDC General Purpose, 10A@277VAC General Purpose, 1/2hp@125VAC 12VDC, 24VDC, 36VDC, 48VDC, 110VDC, 220VDC, 12VAC, 24VAC, 36VAC, 48VAC, 110VAC, 120VAC, 220VAC, 240VAC PC Pin, Solder Lug
CIT Relay and Switch J152 Series UL Approved Relay
 J152 Series UL Approved, TUV Approved 2A, 3A, 4A, 2B, 3B, 4B, 2C, 3C, 4C UL: 2 & 3 Pole 10A@220VAC & 28VDC General Purpose, 4 Pole 5A@220VAC & 28VDC General Purpose; TUV: 2 Pole 5A@220VAC & 28VDC 12VDC, 24VDC, 110VDC, 12VAC, 24VAC, 110VAC, 120VAC, 220VAC PC Pin, Solder Lug
CIT Relay and Switch J850 Series UL Approved Relay
 J850 Series UL Approved PC Pin, Solder Lug 1A@30VDC Resistive, .5A@125VAC Resistive 3VDC, 5VDC, 6VDC, 9VDC, 12VDC, 24VDC PC Pin
CIT Relay and Switch J850SM Series UL Approved Relay
 J850SM Series UL Approved 2C 1A@30VDC Resistive, .5A@125VAC Resistive 3VDC, 5VDC, 6VDC, 9VDC, 12VDC, 24VDC PC Pin
CIT Relay and Switch L114FL Series UL Approved Relay
 L114FL Series Latching, UL Approved 1A, 1C NO: 16A@250VAC Resistive 50K cycles 85C; NC 16A@250VAC Resistive 50K cycles 85C 3VDC, 5VDC, 6VDC, 9VDC, 12VDC, 24VDC PC Pin
CIT Relay and Switch L115F1 Series UL Approved Relay
 L115F1 Series Latching, UL Approved 1A, 1C NO: 30A@277VAC Resistive 6K cycles 25C, 40A@277VAC Resistive 6K cycles 25C, 50A@277VAC Resistive 6K cycles 25C; NC: 30A@277VAC Resistive 6K cycles 25C, 40A@277VAC Resistive 6K cycles 25C, 50A@277VAC Resistive 6K cycles 25 5VDC, 12VDC, 12VDC, 48VDC PC Pin
CIT Relay and Switch L115F2 Series UL Approved Relay
 L115F2 Series Latching, UL Approved 1A, 1C NO: 30A@277VAC Resistive, 40A@277VAC Resistive, 50A@277VAC Resistive; NC: 30A@277VAC Resistive, 40A@277VAC Resistive, 50A@277VAC Resistive 5VDC, 12VDC, 24VDC, 48VDC PC Pin
