Features

• .100" (2.54mm) Contact Spacing x .300" (7.62mm) Row Spacing
• Accepts .125" (3.18mm) Nominal Thickness P.C. Board
• Contact termination options include P.C. Tail, Wire Hole and .025" (0.64mm) Square Wire Wrap
• High Profile Insulator Body .600" (15.24mm)
• Single or Dual Row Configurations
• Variety of Mounting Options
• Accepts In-Contact Polarizing Keys
• Automatic Wire Wrap Positioning Holes
• RoHS Compliant

Specifications

Insulator Material	UL 94V-0 Diallyl Phthalate, Green Color
Contact Material	Copper Alloy
Contact Plating	Gold Plating on mating area and Tin Plating on tails with Nickel underplating all over
Current Rating	3 Amperes
Contact Resistance	10 milliohms maximum
Dielectric Withstand Voltage	1200 VAC rms at sea level between adjacent contacts
Insulation Resistance	5000 Megaohms minimum
Operating Temperature	-65°C to +125°C
Insertion Force	16oz (4.45N) maximum per contact pair when tested with .135" (3.43mm) thick gauge
Withdrawal Force	1oz (0.28N) minimum per contact pair when tested with .115" (2.92mm) thick gauge
