Features

• .156" (3.96mm) Contact Spacing x .200" (5.08mm) Row Spacing
• Accepts .062" (1.57mm) Nominal Thickness P.C. Board
• High Profile Insulator Body, .630" (16.00mm)
• Press Fit Contact Termination Option include .031" (0.79mm) Square Wire & P. C. Tails
• Modular Design permits any Connector Length Assembly
• Accepts between Contact and In-Contact Polarizing Keys
• RoHS Compliant

Specifications

Insulator Material	UL 94V-0 Diallyl Phthalate, Green Color
Contact Material	Copper Alloy
Contact Plating	Gold Plating Over Nickel for Entire Contact
Current Rating	5 Amperes
Contact Resistance	10 milliohms maximum
Dielectric Withstand Voltage	1800 VAC rms at sea level between adjacent contacts
Insulation Resistance	5000 Megohms minimum
Operating Temperature	-65°C to +125°C
Insertion Force	16oz (4.45N) maximum per contact pair when tested with .070" (1.78mm) thick gauge
Withdrawal Force	1oz (0.28N) minimum per contact pair when tested with .054" (1.37mm) thick gauge
