Features

• .100" (2.54mm) Contact Spacing x .140" (3.56mm) Row Spacing
• Accepts .062" (1.57mm) Nominal Thickness P.C. Board
• Low Profile Insulator Body, .437" (11.10mm)
• Contact Termination Options include P.C. Tail, Wire Hole and Extender Board Bends
• Single or Dual Row Configurations
• Variety of Mounting Options
• Accepts between Contact and In-Contact Polarizing Keys
• RoHS Compliant & UL Certified

Specifications

Insulator Material	UL 94V-0 Thermoplastic Polyester. DAP Material is available upon request
Contact Material	Copper Alloy
Contact Plating	Gold Plating on mating area and Tin Plating on tails with Nickel underplating all over
Current Rating	3 Amperes
Contact Resistance	10 milliohms maximum
Dielectric Withstanding Voltage	1200 VAC rms at sea level between adjacent contacts
Insulation Resistance	5000 Megaohms minimum
Operating Temperature	-40°C to +105°C
Insertion Force	16oz (4.45N) maximum per contact pair when tested with .070" (1.78mm) thick gauge
Withdrawal Force	1oz (0.28N) minimum per contact pair when tested with .054" (1.37mm) thick gauge
