Features

• .156" (3.96mm) Contact Spacing
• Available in Plug and Receptacle.
• Edacon Hermaphroditic Contact Mating Design
• Contact Termination Options include Crimp, P.C. Tail, Wire Hole, Wire Wrap and Taper Tail
• Tools are Available for Contact Installation, Removal and Crimping
• RoHS Compliant

Specifications

Insulator Material	Nylon UL 94V-0, White Color
Contact Material	Copper Alloy
Contact Plating	Gold Plating over Nickel over entire contact
Current Rating	8.5 Amperes
Contact Resistance	10 milliohms maximum
Dielectric Withstanding Voltage	2000 VAC rms at sea level
Insulation Resistance	5000 Megaohms minimum
Operating Temperature	-40°C to +105°C
Insertion Force	2 to 16 Oz (0.56 to 4.45N) per contact position
Withdrawal Force	2 to 16 Oz (0.56 to 4.45N) per contact position
