Features

• Up to 480 Mbps communication speed for standard USB 2.0
• Up to 5 Gbps communication speed for standard USB 3.0
• Industry standard plug and play technology - 'Hot Pluggable'
• Compatible with synchronous and asynchronous data transfer
• Data and power combined in one small package
• RoHS compliant

Specifications

Insulator Material	UL-94V-0 Thermoplastic
Contact Material	Copper Alloy
Contact Plating	Nickel under plating with gold plating on contact areas and tin plating on tails
Shell Material	Brass with nickel plating
Insertion Force	35N maximum
Withdrawal Force	10N minimum

Documents and Downloads

Document	File Type	File Size	Download
690P Series Datesheet	PDF	aaa KB
