Features

• C/MOS Digital Circuitry
• Time Delays To 1000 Minutes
• No First Cycle Effect
• Fully Solid State And Encapsulated
• 0.5% Repeat Accuracy
• Six Different Modes Of Operation
• Output Current Ratings To 25 Amp Steady State, 250 Amp Inrush
• Low Cost Mounting And Termination
• Fixed Or Adjustable Time Delays
• UL/cUL Recognized



Series: HBS

Mode Of Operation	Rating	Output	Form	Time Range	Repeat Accuracy
Delay On Break	2.5-25A	Solid State	SPST	0.05 Sec. to 1,000 Mins.	0.5%

Series: HIS

Mode Of Operation	Rating	Output	Form	Time Range	Repeat Accuracy
Interval	2.5-25A	Solid State	SPST	0.05 Sec. to 1,000 Mins.	0.5%

Series: HMS

Mode Of Operation	Rating	Output	Form	Time Range	Repeat Accuracy
Delay On Make	2.5-25A	Solid State	SPST	0.05 Sec. to 1,000 Mins.	0.5%

Series: HRS

Mode Of Operation	Rating	Output	Form	Time Range	Repeat Accuracy
Recycle	2.5-25A	Solid State	SPST	0.05 Sec. to 1,000 Mins.	0.5%

Series: HSS

Mode Of Operation	Rating	Output	Form	Time Range	Repeat Accuracy
Single Shot	2.5-25A	Solid State	SPST	0.05 Sec. to 1,000 Mins.	0.5%

Series: HTS

Mode Of Operation	Rating	Output	Form	Time Range	Repeat Accuracy
Trailing Edge Triggered	2.5-25A	Solid State	SPST	0.05 Sec. to 1,000 Mins.	0.5%

Downloads

Document	File Type	File Size	Download
HS Series Datasheet	PDF	1.1 MB KB
