Heavy duty 30A general purpose power relays.
UL/CUL (UL 508 and 873), VDE safety approvals
Optional for open frame, dust cover, sealed type and with /without quick terminal on top, etc.
High insulation type and high dielectric strength type avaiable.
Contact gap to 1.9mm, high dielectric strength 4000Vrms.
High CTI 250 material or product comply with IEC 60335-1 are available.
Ideal for HVAC, UPS and power supply, Home Appliances.
Complies with RoHS-Directive 2011/65/EU
Optional for explosion-proof version.

Part Series:	832
Contact Configuration	1A, 1B, 1C
Contact Rating(Resistive Load)	1A: 30A 240VAC; 1B: 15A 240VAC; 1C: NO/20A NC/10A 240VAC
Coil Voltage	DC: 5 - 110V
Power Consumption	DC: 0.93 / 1.1W
