Typical Specifications

Rating（max.）/（ min.）（Resistive load） 0.1A 12V DC / 1mA 5V DC
Contact resistance （Initial / After operating life） 30mΩ max. / 80mΩ max.
Operating force 2-position 3-position
3±1.5N a, c → b 2±1N
b → a, c 3±1.5N
Operating life Without Load 10,000 cycles
With Load 10,000 cycles（ 0.1A 12V DC）

Downloads

Document File Type File Size Download
SSSS9 Series Datasheet PDF 1.2 MB
